304 Stainless Steel Trash Drawer Combo | Built-In for BBQ, Cafe & Restaurant Counters
| Share | |
|---|---|
| Categories | Commercial Stainless Steel Cabinets |
| Brand | Samsink |
| Model | SK-OD-28 |
| Material | 304 stainless steel + galvanized sheet |
| Overall Dimensions | 28" W x 19.6" D x 20.1" H (711 x 498 x 511 mm) |
| Net Weight | approx. 30.8 kg |
| Installation | Built-in / insert into service counter |
| Surface Finish | Brushed hairline |
| Drawer Slides | Mute heavy-duty ball bearing slides |
| Bin Configuration | 2 removable waste bins + 3 storage drawers |
| Application | Outdoor BBQ kitchens, cafe bars, restaurant counters, beverage service stations |
Trash Drawer Combo for BBQ Islands, Cafe Counters & Restaurant Bars
A 304 stainless steel trash drawer combo that combines two removable waste bins, a BBQ access door and three storage drawers in one built-in cabinet. Engineered for outdoor BBQ kitchens, cafe counters, restaurant bars and beverage service stations that need weather-resistant, easy-clean storage within arm’s reach.
Material
304 stainless steel + galvanized sheet
Dimensions
28" W × 19.6" D × 20.1" H
Net Weight
approx. 30.8 kg
Installation
Built-in service counter
Surface
Brushed hairline
Application
BBQ / cafe / restaurant / beverage counter
Built-In Storage That Works as Hard as Your Service
Every module solves a real pain point reported by outdoor kitchen builders, cafe operators and restaurant owners.
Dual Waste Bin Compartment
The pull-out trash compartment holds two removable bins, so guests and staff can separate waste from recycling at the grill or behind the counter.
Cleaner service at any counter
Three-Drawer Storage Layout
Three stainless drawers (5.93" front height each) organize tools, towels, gloves, menus and bar accessories within easy reach.
Faster prep workflow for BBQ, cafe, restaurant
Integrated Frame, No Welded Seams
The frame is processed in one piece — no welding gaps, no visible joints, no crevices that trap grease, coffee grounds or food residue.
Premium look, less scrubbing
Mute Heavy-Duty Ball-Bearing Slides
Full-extension slides carry loaded drawers without wobble, and a damping mechanism closes them silently during peak service.
Quiet, smooth daily use in customer-facing areas
Dimensions & Cut-Out Planning
Designed to drop into a standard 28" wide opening. The engineered diagram below marks every critical dimension, so cabinet builders can install it without rework across BBQ islands, cafe counters and restaurant bars.
- Overall: 28" W × 19.6" D × 20.1" H (711 × 498 × 511 mm)
- Drawer front height: 5.93" each
- Trash door front width: 11.22"
- Recommended opening depth: ≥ 22" for hose and vent clearance
Where This Combo Fits
From outdoor grill stations to indoor hospitality counters. One cabinet, four front-of-house roles.
Complete Specifications
Product Data
| Model | SK-OD-28 |
|---|---|
| Material | 304 stainless steel + galvanized sheet |
| Overall dimensions | 28" W × 19.6" D × 20.1" H |
| Net weight | approx. 30.8 kg |
| Finish | Brushed hairline |
| Drawer slides | Mute heavy-duty ball bearing |
| Door / drawer fronts | Brushed stainless steel |
| Bin configuration | 2 removable waste bins + 3 storage drawers |
| Application scenes | Outdoor BBQ kitchens, cafe counters, restaurant bars, beverage stations |
Ordering & Service
| MOQ | To be confirmed (sample / project order) |
|---|---|
| Lead time | 25–40 days after order confirmation |
| Customization | OEM / ODM, logo, dimensions, packaging |
| Trade terms | FOB Foshan, EXW, or as agreed |
| Payment | T/T, L/C at sight |
| Certification | Material SGS test report available |
| Warranty | 2-year manufacturing warranty |
| After-sales | Replacement parts & technical support |
Frequently Asked Questions
- What opening size is needed for this trash drawer combo?
- Plan the cabinet opening for 28" W × 19.6" D × 20.1" H, plus about 0.5" side clearance for adjustment and airflow. Suitable for BBQ islands, cafe counters and restaurant bars.
- Can the trash drawer be used with standard garbage bags?
- Yes. Both inner bins are removable and accept standard small trash bags, so liners can be swapped in seconds during service.
- How does it handle rain, humidity and coffee spills?
- 304 stainless steel fronts and a galvanized back panel resist rust and corrosion. A covered BBQ island roof or indoor cafe location still extends service life.
- Is it suitable for both outdoor BBQ kitchens and indoor cafe counters?
- Yes. The 304 stainless steel + galvanized sheet construction is rated for outdoor grill islands and indoor hospitality counters. We confirm the exact mounting depth with you before production.
- Do you offer OEM sizes or branding?
- Yes. Samsink supports OEM / ODM with custom widths, depths, handle styles, finish and packaging. Send your project specs for a quote.
- What is the MOQ and lead time for this drawer combo?
- Sample and small project orders are welcome. Standard production runs 25–40 days after order confirmation, depending on quantity and customization level.
- How is each unit packaged for export shipping?
- Every unit is foam-lined and packed in a reinforced export carton, with corner protection for long-distance ocean freight. Custom packaging and retail-ready boxes are available on request.
- What quality checks are done before shipment?
- Each combo passes a slide-operation test, surface finish inspection and dimension check before packing. A material SGS test report for the 304 stainless steel is available on request.
Get a Project Quote
Tell us your application (BBQ island, cafe counter, restaurant bar or beverage station), quantity, destination port and any custom size or branding needs. We will reply with pricing, lead time and packaging options within 24 hours.
